| Specifications | |
| Material | BK7 Grade Aoptical glass |
| Dimension Tolerance | ±0.2mm |
| Clear Aperture | >90% |
| Flatness | λ/4@632.8nm |
| Beam Deviation | <3 arc minutes |
| Surface Quality | 60/40 |
| Coating | Partial reflectance on hypotenuse face |
| AR coating on all entrances | |
| T/R | 50/50±5%, T=(Ts+Tp)/2, R=(Rs+Rp)/2 |
| Damage Threshold | >500mJ/cm2, 20ns, 20Hz, @1064nm |
| 產品 | 型號 / 敘述 | 交期 | 單價 | 數量 | 購物車 |
 |
P-V3MUBC0104B
cube/10.0*10.0*10.0mm/450-650nm |
3 weeks |
NT$2280 |
||
 |
P-V3MUBC0134B
cube/12.7*12.7*12.7mm/450-650nm |
3 weeks |
NT$2580 |
||
 |
P-V3MUBC0204B
cube/20.0*20.0*20.0mm/450-650nm |
3 weeks |
NT$3000 |
||
 |
P-V3MUBC0254B
cube/25.4*25.4*25.4mm/450-650nm |
3 weeks |
NT$3240 |
||
 |
P-V3MUBC0106B
cube/10.0*10.0*10.0mm/650-900nm |
3 weeks |
NT$2280 |
||
 |
P-V3MUBC0136B
cube/12.7*12.7*12.7mm/650-900nm |
3 weeks |
NT$2580 |
||
 |
P-V3MUBC0206B
cube/20.0*20.0*20.0mm/650-900nm |
3 weeks |
NT$3000 |
||
 |
P-V3MUBC0256B
cube/25.4*25.4*25.4mm/650-900nm |
3 weeks |
NT$3240 |
||
 |
P-V3MUBC0109B
cube/10.0*10.0*10.0mm/900-1200nm |
3 weeks |
NT$2280 |
||
 |
P-V3MUBC0139B
cube/12.7*12.7*12.7mm/900-1200nm |
3 weeks |
NT$2580 |
||
 |
P-V3MUBC0209B
cube/20.0*20.0*20.0mm/900-1200nm |
3 weeks |
NT$3000 |
||
 |
P-V3MUBC0259B
cube/25.4*25.4*25.4mm/900-1200nm |
3 weeks |
NT$3240 |
