Male Description | Female Description | ||||||||||
Pin
|
Description | Pin | Description | Pin | Description | Pin | Description | ||||
1
|
Home(output 0V NPN) | 10 | - | 1 | - | 10 | - | ||||
2
|
GND | 11 | - | 2 | - | 11 | - | ||||
3
|
Forward Limit Switch(output 0V NPN) | 12 | - | 3 | - | 12 | Encoder Z+ | ||||
4
|
Reverse Limit Switch(output 0V NPN) | 13 | - | 4 | Encoder Z- | 13 | Encoder B+ | ||||
5
|
Vcc +(24VDC) | 14 | - | 5 | Encoder B- | 14 | Encoder A+ | ||||
6 | 2 Phase Motor B+ | 15 | 6 | Encoder A- | 15 | - | |||||
7 | 2 Phase Motor B- | 7 | - | - | |||||||
8 | 2 Phase Motor A- | 8 | 5V | - | |||||||
9 | 2 Phase Motor A+ | 9 | 0V | - |
