2-100
2-100
| 單片式標準狹縫 寬100um |
| 型號 : | 2-100 |
|
狹縫尺寸:
|
100um X 3mm
|
|
公差 :
|
±4um
|
|
外徑 :
|
9.53mm
|
|
狹縫厚度 :
|
12.7um |
|
針孔材質 :
|
300 Series Stainless Steel
|
.png) |
重量 : 0.01KG 發貨日 : In Stock
價格:NT$3080
| 型 號 | 狹縫尺寸 | 公差 | 外徑 | 狹縫厚度 | 狹縫材質 | ||
| 2-2.5 | 2.5um X 3mm | +1um/-0.5um | 9.53mm | 127um | ※B 300 Series Stainless Steel +(BeCu or Ni) | ||
| 2-5 | 5um X 3mm | ±1um | 9.53mm | 12.7um | 300 Series Stainless Steel | ||
| 2-10 | 10um X 3mm | ±1um | 9.53mm | 12.7um | 300 Series Stainless Steel | ||
| 2-25 | 25um X 3mm | ±2um | 9.53mm | 12.7um | 300 Series Stainless Steel | ||
| 2-50 | 50um X 3mm | ±2um | 9.53mm | 12.7um | 300 Series Stainless Steel | ||
| 2-100 | 100um X 3mm | ±4um | 9.53mm | 12.7um | 300 Series Stainless Steel | ||
※B : 2-2.5 & 1-2.5H 不鏽鋼針孔雙面會增加鎳(銀色)或鈹銅(金色) 整體厚度為 127um ,不銹鋼厚度為12.7um
