Specifications | |
Material | BK7 Grade A, UV grade Fused Silica |
Dimension Tolerance | +0.0/-0.2mm |
Thickness Tolerance | ±0.2mm |
Clear Aperture | >90% |
Parallelism | <30 arc seconds |
Surface Quality | 60/40 |
Flatness | <λ/4@633nm per 25mm |
Chamfer | Protected <0.5mmx45deg |
T/R | 50/50±5% at specific polarization state |
Coating(AOI=45deg) | S1: Partial reflectance coating |
S2: AR coating | |
Damage Threshold | >5J/cm2, 20ns, 20Hz, @1064nm |
